Shoei vs. Arai Helmets

In the store we constantly hear a question "What is the difference between X and Y?" Most often, customers solving X and Y ask what sets Arai and Shoei apart.

Despite all the technological changes and innovations of the last decade, the Arai and Shoei are still considered an ambitious choice for many riders looking for a high-end helmet. But the question is, what separates the two premium Japanese manufacturers?

This article is now about which one is better, but to shed some light on the similarities and differences between the two manufacturers in a few key areas.

.



Founded by Hirotake Arai in 1937, Arai Helmet was originally a hat manufacturer. The hard hat changed with the introduction of the construction safety helmet in the late 1940s. Motorcycle helmets followed shortly after the introduction of the lineup in 1952.

After World War II, Japan operated as a closed economy and motorcycle helmets were difficult to import. While it can be argued that Mr. Arai grabbed an opportunity, most reports suggest that he was simply looking for a good helmet to protect himself on the motorcycle. So he decided to build his own.

The Arai used a fiber reinforced plastic (FRP) shell and in 1958 switched from cork to an expanded polystyrene inner liner. This has been the basic standard for helmet manufacturing for the past 60 years. While American manufacturer Bell Helmets introduced the world's first full-face helmet, the Bell Star, in 1963, the Arai would soon follow. Arai introduced Japan's first full-face helmet in March 1967.

.

.

In a 2015 interview with Cycle World, Hirotech Arai's son, Arai's president and CEO, Michio Arai, talked about his father's legacy.

“My father did not know much about chemicals. He read an article on fiberglass. "It could be good," he said. I still don't know what he did, but he went to a college professor and found out how to make a fiberglass hull. There was another headset company: Bell. Roy Richter was the owner. I knew him very well. My dad started on the other side of the world, so we don't know who was first, but my dad didn't copy anyone.



Eitaro Kamata founded Kamata Polyester Company in 1954 before shifting production towards motorcycle helmets in 1959. Unlike Arai, who shifted into motorcycle helmets for personal use, Kamata immediately began designing Shoei Helmets with the focus on motorcycle racing. One of their earliest achievements was being adopted as Honda’s official race helmet in 1965.

In the early 1970s, fiberglass was the material of choice for the manufacture of helmet shells. This lasted until 1976 when Shoei introduced the first carbon fiber and Kevlar helmet, the GR-Z. It was a tremendous revolution that is one of Shoei's most notable achievements. They were the first to introduce ventilation into their helmet design as well as the first no-cover face shield system, which debuted on the 1990 Shoei X-8. The no-cover face shield is a feature that has been adopted by almost everyone. Other full face helmet manufacturers.

.

.



Shoei’s focus on comfort, as an aspect of safety, has led to the implementation of features like the podless face shield system, which reduces wind resistance and thus neck fatigue as well as wind noise. It has also allowed them to create helmets like the GT-Air II and Neotec II, which sacrifice a SNELL rating in order to include comfort-first features like a drop-down sun visor and in the case of the Neotec, a modular design. Arai simply refuses to risk sacrificing the integrity of their shell design to include such niceties.



Arai’s shell design is built around their philosophy of the “R75 shape,” which refers to the continuous curve radius of at least 75 mm. Arai claims a better dispersion of kinetic energy as well as minimizing the potential for the helmet to catch on rough surfaces, thus reducing unwanted rotational forces.

While computer animation has worked its way into the factory when it comes to cutting the face opening or during certain steps in the paint process, the majority of the shell is still built by hand. Their shells are constructed using a proprietary mechanically expanded fiber mat which varies in its chemical composition depending on the helmet. The “Complex” in Arai’s “Complex Laminate Construction” refers to all of the different layers and designs that are incorporated into one shell.

.

.

.

Shoei’s Advanced Integrated Matrix (AIM and AIM+) shells are extremely sophisticated and designed for the ultimate protection. Again, with Shoei, the definition of ultimate protection also includes taking the rider’s comfort into account.

These shells are designed from multiple layers of varying proprietary fibers. An AIM shell has five layers: an inner layer of  fiberglass followed by special fibers, 3D organic fibers, organic fibers, and finally an outer layer of fiberglass. The AIM+ shell adds in a sixth layer of high performance organic fibers between the special fibers and 3D organic fibers. While this all sounds nice and complicated, you’re probably (like myself) wondering what it means.



Shoei claims that this allows them to build a stronger shell that’s also competitively lightweight. The shell itself is also more elastic for impact absorption while simultaneously providing more strength and resistance to penetration, due to the use of special proprietary fibers.

Because of Shoei’s philosophy on the overall comfort of the rider, considerable consideration is given to the shape and subsequent wind resistance the shell creates. The idea being that a more aerodynamically designed helmet can reduce turbulence and rider fatigue during long days in the saddle. It also contributes to reducing the noise created by the helmet as it cuts through the air.

EPS stands for expanded polystyrene and it’s the interior foam liner which works to absorb the impact. In the event of a crash, the cells in the liner are crushed one by one, slowing the transmission of forces to your head. Once the cells have been destroyed, they no longer have any ability to protect your head. This is why it’s important to replace a helmet after it has suffered a crash.

Arai utilizes a one-piece EPS using up to five different foam densities, depending on the model. When referring to “density” in regards to EPS liners, the main focus is on the amount of force needed to crush the foam. A heavier, denser foam is used to protect against high-speed impacts while a softer, less dense foam is used for protection during slower, low-speed impacts. Arai designs their EPS liners with different density foams located at specific areas in the helmet to maximize the impact protection provided.

Unlike Arai's one-piece liner, Shoei’s EPS features a dual-layer, multi-density design. The top portion of the inner EPS liner is composed of a softer density foam for immediate impact absorption. The outer portion of the EPS liner is made from a medium-density foam designed for protection at higher speed impacts. Depending on the model, there is additional multi-density functionality built in to further tune the helmet’s protective capabilities.

.

.

Arai’s approach is to produce helmets featuring three different internal head shapes, which vary per individual model. Helmets are manufactured with either a long oval, round oval, or intermediate oval fitment. Because of this, fit isn’t universal throughout all Arai helmets. Just because one fits you perfectly, that doesn’t mean another Arai model will .

That being said, riders can fine-tune the fit of individual models. Arai provides a wide selection of interior liners and cheek pads in a variety of thicknesses. Additional adjustments can be made using micro-fit pads within the cheek-pad covers or by swapping liners between helmet models.

Shoei produces nearly all of their helmets for the American market with one internal shape: intermediate oval. While there are some small variations between the models, a Shoei helmet will usually fit 80 percent of the riding public perfectly. Shoei is not the ideal choice for those riders with heads that fall in the extremes of overly round or long oval.

Shoei also provides an array of varying internals. Both cheek pads and liners are available in different thicknesses and can be swapped out or adjusted to fine tune a helmet’s fitment.



As I stated in the beginning of this article, there is no clear “winner,” just different schools of thought about the best approach to offering premium, hand-made head protection to motorcyclists.

.

.

I trust both Shoei and Arai helmets (among others) to keep me safe in a variety of settings. On the track, I prefer the fit of the Arai Corsair X to the Shoei X-Fourteen. However, for off-road riding, the Shoei VFX-EVO trumps the Arai VX-Pro. But those are my opinions based on which helmet works best for my particular head shape, comfort tolerances, and preferred riding style.

My advice is to focus on the features that are most important to you and the type of riding you are looking to tackle, consider the information above, and make an educated decision about which helmet is best for you.



Author: Spurgeon Dunbar
